PRINTING

• Print Mode: Single- or Dual-Sided
• Print Type: Direct Dye-Sublimation
• Print Area: Edge to Edge
• Resolutions: 300dpi (Color & Mono), 600 & 1200dpi (Mono only)

CARD

• Card Feeding: Automatic
• Card Size: ISO CR80 or ISO CR79 (Option-Factory installed)
• Card Thickness: 0.38mm (15mil) ~ 1.0mm (40mil)
• Card Type: PVC, PET, Composite PVC

Print Speed

• Monochrome: 5 sec./card (720 cards/hour)
• YMCKO: Max. 17 sec./card (212 cards/hour)
• YMCKOK: Max. 22 sec./card (164 cards/hour)

CAPACITY

• Input Hopper: Card100 Cards / 200 Cards with cover open
• Output Hopper: CardFront : 40 Cards / Rear : 100 Cards (Optional Rear-side Stacker)

LAMINATING

• Mode: Single & Dual
• Film (Clear & Holographic): 0.6mil, 1.0mil
• Speed (Simultaneous): 22 sec./card (YMCK, Single Lamination)
• Speed (Simultaneous): 32 sec./card (YMCKK, Single Lamination)
• Speed (One by One): 43 sec./card (YMCK, Single Lamination)
• Speed (One by One): 53 sec./card (YMCKK, Single Lamination)

SYSTEM

• Memory: 64MB RAM
• Interface: 2 Line LCD / 2 LED Buttons
• Supported Platforms: Microsoft Windows 7/ 8 /10, Mac OS, Linux
• Communication: USB, Ethernet, WiFi (Option)
• Power Supply: Free Voltage (AC 100/ 220V, 50~60Hz)
• Power Consumption: 96W
• Temperature: 15~35°
• Humidity: 35~70%

SECURITY

• Physical Lock: Input Hopper, Ribbon & Film (Option)
• Station Itself: Kensington Lock (Option)

DIMENSIONS

• Milimeter: 165 (W) x 675 (L) x 210 (H)
• Inch: 6.5 (W) x 26.6 (L) x 8.3 (H)

WEIGHT

• Kg/Lbs Approx. 8.8 kg/19.4 lbs

ENCODING OPTION

• Magnetic: ISO 7811 (Track I, II, III Read/ Write, HiCo/ LoCo), JIS II
• Contact: ISO 7816 A/B/C Card, ISO 7816 1/2/3/4 Microprocessor Card
• Contactless: ISO 14443 (Type A/ B), MIFARE, DESFIRE, iCLASS, ISO 18092(NFC), Felica

CERTIFICATIONS

• Certifications: CB, CE, FCC, KC, CCC
