D-LINK / NCB-FS09D-LCSC-1 / LC-SC Single M0de Duplex Patch Cord 1M
Product Features
- Adopts high-precision ceramic ferrule with good concentricity.
- Good geometry characteristics of apex offset & radius of curvature & fiber height.
- Compact & strong crimping offers exceptional tensile strength in cable assemblies.
- 100% inspected for optical characteristics & fiber end face finish.
- Low insertion loss & return loss, clean and scratch-free end faces.
- Good performance endurance under circumstances changing.
Product Specifications
| Connector Type SC/ST/FC/LC/MTRJ | |||
| Optical Fiber | Single-mode (OS2) G652D, G657A | Multi-mode OM1, OM2, OM3, OM4 | |
|
Cable Type |
PVC & LSZH on request,OFNR or OFNR LSZH with kevlar for the APC type | ||
| 0.9mm/2.0mm/3.0mm Simplex & Duplex | |||
| Cable Color, Length | Yellow for single mode, orange for multi-mode & aqua for OM3 1m, 2m and 3m. Other lengths on request. | ||
| Optical Specification | Insertion Loss | Typical: ≤0.2dB, Max. 0.3dB (MTRJ: Max. 0.5dB) | Typical: ≤0.2dB, Max. 0.3dB (MTRJ: Max. 0.5dB) |
| Return Loss | PC≥45dB, UPC≥50 dB, APC≥60dB | ≥30dB | |
|
Mechanical Specification |
Ferrule | Ceramic, (MTRJ: PS-Polyphenylene Sulphide) | |
| Apex Offset | < 50um | ||
| Fiber Height | ±100nm | ||
| Radius of Curvature | 7mm R < 25mm(Excluding MTRJ) | ||
| Repeatability | ≤0.2dB 1,000 times mating cycles | ||
| Working Temperature | -40ºC ~ +85ºC | ||
| Storage Temperature | -40ºC ~ +85ºC | ||
